Iraqi Common Brick Class A
CLASS A: This type of brick is used in partitions of buildings and load bearing foundations that is susceptible to erosion due to climate or nature or bricks of walls facing outside susceptible to erosion.
Dimension
Height x Width x Length
75 mm (height) x 115 mm (width) x 240 mm (length)
Hollowness
19 Holes
Percentage of holes in any dimension less than 25% of the volume
Bearing Capacity
kg/cm2
Minimum 245 kg/cm2 per brick equivalent to 24 N/ mm2
Water Absorption Rate
%
Water Absorption Rate is 14%-15% per brick
Efflorescence
salt on the surface of a brick material, where it forms a white coating.
Level of Efflorescence Low to None
Deviations
±
Less than ±3% in Width Height and Length
Weight
kg per brick
2.6-2.7 kg per brick
Palletization
Number of Bricks per Pallet
400 bricks per pallet
Palletization
Dimension and Weight
Dimension 920 mm (height) x 975 mm (width) x 960 mm (length)
Weight 1,040kg-1,080kg per Pallet
Wall
Number of Bricks per square meter of wall
96 bricks per sqm- on 240mm length
48 bricks per sqm- on 115mm length
Fire Resistance
Period (minutes)
120 minutes - 240 minutes
Firing at 900 C
Thermal Insulation
Thermal conductivity
(W/m K)
k-value or λ
0.6
Sound Insulation
Rw (dB)
40dB
Load Bearing Brick 200 mm (width)
The Future of Construction
Ashur Brick Load Bearing Bricks are vertically perforated bricks utilizing the latest french technology in construction materials. Highly engineered bricks allowing you to build up to G+3 floors and save on Reinforced concrete costs. The concept of load bearing construction will enable an engineering revolution in the construction industry.
Dimension
200 mm (height) x 200 mm (width) x 400 mm (length)
Hollowness
Percentage of holes in any dimension 30%-35% of the volume
Bearing Capacity
Minimum 90 kg/cm2 per brick equivalent to 9 N/ mm2; each brick can withstand minimum load of 90 tonnes
Water Absorption Rate
Water Absorption Rate is 12%-13% per brick
Efflorescence
Level of Efflorescence Low to None
Deviations
Less than ±1% in Width Height and Length
Weight
13-14.5 kg per brick
Palletization
102 bricks per pallet
Palletization
Dimension 1200 mm (height) x 1200 mm (width) x 1200 mm (length)
Weight 1,326kg-1,479kg per Pallet
Fire Resistance
240 minutes
Firing at 900 C
Thermal Insulation
k-value or λ
0.6
Sound Insulation
45dB
Download Important Documents
List of Import Documents from Ashur Brick
This document contains the sampling and testing method for common Iraqi bricks ( Dimension,Compressive Strength, Water Absorption, Efflorescence and more)
COLOUR AND TEXTURE VARIATION
Our clay bricks are made from naturally occurring minerals that are kiln fired to lock in their colour and strength for life.
The composition of the raw materials as well as the firing process may cause each run to differ. The resulting colour and texture variation is inherent in the process and part of the appeal of our natural products.
The product images in our brochures and on this website give a general indication of colour for your preliminary selection.
We recommend you also view current product samples and look at actual finished projects before making your final selection.
